Product Model
Avocent Matrix MXR5110 DVI-I Receiver
The Avocent Matrix Digital High Performance KVM system provides a highly scalable and configurable way to connect hundreds of users to thousands of servers and workstation equipment in a secure, real-time manner. By providing high definition video, audio, and exceptional USB performance is ideal for control room and user extension applications in Government, Broadcast, Post Production, Enterprise Data Centers, Industrial, and Transportation environments.
Quick Access
Specifications
Technical Specifications
Avocent Matrix MXR5110 DVI-I Receiver
- Product Overview
- Input Ports
- USB x 6
- Output Ports
- Speaker & Mic
- Video Connection
- 1 x DVI-I
- Video Resolution
- 1920x1200
- Graphic Mode
- Input Ports
- USB x 6
- Output Ports
- Speaker & Mic
- Video Connection
- 1 x DVI-I
- Video Resolution
- 1920x1200
- Internal Modem
- No
- Service Processor support
- NO
- Power Description
- Power Supply(s)
- Yes
- Input Power (Maximum)
- 100-240V 50/60 Hz
- Interfaces/Ports
- Network Interface(s)
- 1 x RJ45
- USB ports
- 1 x USB Type B
- USB Hub Support
- USB 2.0 with Class Control
- Operational Conditions
- Operating Temperature
- 0 to 45ºC / 32 to 113ºF
- Humidity
- 10% to 90% non-condensing
- Storage Temperature
- -31° to 158°F (-35° to 70°C)
- Physical Characteristics
- Weight
- 1.6 lbs
- Weight
- 0.73 kgs
- Height
- 1.21 in
- Height
- 30.73 mm
- Width
- 8 in
- Width
- 203.2 mm
- Depth
- 4.9 in
- Depth
- 124.46 mm
- Miscellaneous
- Agency Approvals
- CE, FCC
- Product Overview
- Input Ports
- USB x 6
- Output Ports
- Speaker & Mic
- Video Connection
- 1 x DVI-I
- Video Resolution
- 1920x1200
- Weight
- 1.6 lbs
- Weight
- 0.73 kgs
- Height
- 1.21 in
- Height
- 30.73 mm
- Width
- 8 in
- Width
- 203.2 mm
- Depth
- 4.9 in
- Depth
- 124.46 mm
Software
Warranties
Technical Specifications
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Avocent Matrix MXR5110 DVI-I Receiver
Warranty : 2 Years
Features
Multi-User Access - Avocent Matrix provides up to hundreds of users with non-blocked access to connected servers and equipment, allowing for multi-user access at any time.
Scalable, Expandable Architecture -Thousands of devices can be connected through cascading and expanding the system is easy to implement.
Intuitive Administration - Through the web interface or Matrix Manager software, a single management system allows you to manage devices, users, and peripherals. Advanced features also exist to establish macros, event notification, high availability, and external API access.
High Performance Video, Audio, and USB - Remotely access applications with a exceptional USB, audio, and resolution up to 1920 x 1200.
