Vertiv™ Liebert® PSI5 UPS, 750-5,000VA Line Interactive AVR, Mini Tower, 1U and 2U Rack/Tower
Compact, Automatic Voltage Regulation (AVR) line-interactive UPS system designed especially for IT applications such as network closets and small data centers. Supports advanced pure sine wave output on battery to safeguard critical IT equipment and electronics. Provides reliable power protection for servers, critical nodes, network workstations, large network peripherals, network routers, bridges, and others. Three form-factors available: 1U rack mount, 2U rack/tower and mini tower.
Saved This Product to Your Dashboard
You just saved this product to your dashboard to view at a later time. You can easily remove the item from your dashboard when you no longer wish to have it saved.
Please login or create an account to save this for later
Vertiv™ Liebert® PSI5 UPS, 750-5,000VA Line Interactive AVR, Mini Tower, 1U and 2U Rack/Tower
Compact, Automatic Voltage Regulation (AVR) line-interactive UPS system designed especially for IT applications such as network closets and small data centers. Supports advanced pure sine wave output on battery to safeguard critical IT equipment and electronics. Provides reliable power protection for servers, critical nodes, network workstations, large network peripherals, network routers, bridges, and others. Three form-factors available: 1U rack mount, 2U rack/tower and mini tower.
Warranty: Vertiv backs all Vertiv™ Liebert® PSI5 UPS systems with two-year, full unit coverage, including the battery. The Vertiv no-hassle, advanced replacement warranty covers all shipping fees and includes next-day delivery, which ensures customers will receive their replacement UPS prior to returning their damaged unit with no questions asked.Specifications
The flexible design of the Liebert® PSI5 allows the UPS to be tower (MT models), 1U rack mountable (1U models), or to be configured as a self-standing tower or to be rack-mounted within a 2U space (RT models). It is available from 750VA to 5000VA with both 120V or 208V models. The Liebert® PSI5 UPS features an innovative advanced line-interactive design incorporating buck/boost Automatic Voltage Regulation (AVR) technology. This protects against utility voltage fluctuation by raising and lowering utility power to the level needed by the connected equipment. It also allows the UPS to prolong battery life by maximizing its time on utility power before going to battery. Models with a capacity of 1500VA and below are not for sale in Vermont, Colorado, Washington.
|
PSI5-750MT120
|
||||||||
|---|---|---|---|---|---|---|---|---|
| 750 VA / 675 W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 97% (Normal Mode) | Input: 5-15P; Ouput: 5 x 5-15R | 9.4 in | 5.7 in | 14.8 in | 24.7 lb |
| See more product information | ||||||||
|
PSI5-1100MT120
|
||||||||
| 1,100 VA / 990 W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 97% (Normal Mode) | Input: 5-15P; Ouput: 5 x 5-15R | 9.4 in | 5.7 in | 14.8 in | 26.0 lb |
| See more product information | ||||||||
|
PSI5-1500MT120
|
||||||||
| 1,440 VA / 1,350 W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 97% (Normal Mode) | Input: 5-15P; Ouput: 6 x 5-15R | 9.4 in | 5.7 in | 19.1 in | 40.1 lb |
| See more product information | ||||||||
|
PSI5-1000RM1201U
|
||||||||
| 1,000 VA / 900 W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 98% (Normal Mode) | Input: 5-15P; Ouput: 5 x 5-15R | 1.7 in | 17.2 in | 20.1 in | 36.4 lb |
| See more product information | ||||||||
|
PSI5-1500RM1201U
|
||||||||
| 1,440 VA / 1,350 W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 98% (Normal Mode) | Input: 5-15P; Ouput: 5 x 5-15R | 1.7 in | 17.2 in | 24.8 in | 45.6 lb |
| See more product information | ||||||||
|
PSI5-800RT120
|
||||||||
| 800VA / 720W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 16.2 in | 28.9 lb |
| See more product information | ||||||||
|
PSI5-1100RT120
|
||||||||
| 1100VA / 990W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 16.2 in | 31.1 lb |
| See more product information | ||||||||
|
PSI5-1500RT120
|
||||||||
| 1500VA / 1350W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 20.1 in | 42.8 lb |
| See more product information | ||||||||
|
PSI5-2200RT120
|
||||||||
| 2200VA / 1920W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: L5-20P; Output: 6 x 5-15R, 1 x L5-20R | 3.5 in | 17.2 in | 24.8 in | 59.1 lb |
| See more product information | ||||||||
|
PSI5-3000RT120
|
||||||||
| 3000VA / 2700W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: L5-30P; Output: 6 x 5-15R, 1 x L5-30R | 3.5 in | 17.2 in | 24.8 in | 70.8 lb |
| See more product information | ||||||||
|
PSI5-5000RT208
|
||||||||
| 4250VA / 3825W | Nominal: 208VAC / Range: 150-281VAC | 208VAC (100/110/115/125 VAC TDU Required) | Up to 96% (Normal Mode) | Input: L6-30P; Output: 4 x L6-30R | 3.5 in | 17.2 in | 24.8 in | 87.7 lb |
| See more product information | ||||||||
|
PSI5-800RT120N
|
||||||||
| 800VA / 720W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 16.2 in | 28.9 lb |
| See more product information | ||||||||
|
PSI5-1100RT120N
|
||||||||
| 1100VA / 990W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 16.2 in | 31.1 lb |
| See more product information | ||||||||
|
PSI5-1500RT120N
|
||||||||
| 1500VA / 1350W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: 5-15P; Output: 6 x 5-15R | 3.5 in | 17.2 in | 20.1 in | 42.8 lb |
| See more product information | ||||||||
|
PSI5-2200RT120N
|
||||||||
| 2200VA / 1920W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: L5-20P; Output: 6 x 5-15R, 1 x L5-20R | 3.5 in | 17.2 in | 24.8 in | 59.1 lb |
| See more product information | ||||||||
|
PSI5-3000RT120N
|
||||||||
| 3000VA / 2700W | Nominal: 120VAC / Range: 75-146VAC | 120VAC (100/110/115/125VAC user-configurable) | Up to 96% (Normal Mode) | Input: L5-30P; Output: 6 x 5-15R, 1 x L5-30R | 3.5 in | 17.2 in | 24.8 in | 70.8 lb |
| See more product information |
Benefits
Features
and power management capability — Local USB or SNMP via optional Vertiv™ Liebert® UNITY communication card
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Find Your Area Contact
Products Support Contacts
Change
Related Products And Services
Provides Web access, environmental sensor data, and third-party customer protocols for Vertiv™ equipment. The cards employ Ethernet and RS-485 networks to monitor and manage a wide range of operating parameters, alarms and notifications. Provides a communication interface to Trellis™, LIFE™ Services, Liebert® Nform, and third-party building and network management applications.
While you may be equipped to handle small UPS battery replacement on your own, having factory-authorized technicians do the work for you augments your busy IT staff with a team of experts who can literally do the heavy lifting for you. We’ll partner with you to ensure continuous power for support of vital business applications by finding the best solution for your needs — from DIY battery replacement to UPS replacement with full service protection.
Managing your small, remote, or dispersed mission-critical IT sites is a major challenge. While outages are not an option, neither is sacrificing your busy IT staff to set up and maintain UPS systems. Vertiv’s Power Assurance Package delivers convenient and cost-effective support for power delivery to your small IT sites.
Additional Resources
How Do You Select a UPS for Power Backup?
Your specific needs should determine your IT power decision. Selecting a UPS for your particular application requires an examination of a number of factors. The load size, location and criticality of the equipment to be protected are key, as well budgetary considerations, when choosing a UPS for power backup.
Power Continuity Services Selector: Renew and Maintain Your Vertiv Single-Phase UPS Population
Power Continuity Services offers flexible and complete lifecycle power renewal options for Liebert® GXT and Liebert® PSI UPS systems. This comprehensive program ranges from customer battery replacement to full-service replacement of battery and UPS with service contracts. Utilize this selector to identify what options are available for your equipment.
