eSure Power Extend Converter, C48/58-1000
The eSure™ C48/58-1000 Power Extend Converter is a compact device that economically boosts voltage up to -58 VDC to support increasing power needs of remote radio heads on cell towers. The eSure C48/58-1000 plugs into an existing DC distribution panel in the same position as a single-pole bullet circuit breaker, conserving usable space.
Guadar este produto no seu dashboard
Você pode guardar este produto no seu dashboard para ve-lo depois. Você pode elimina-lo com facilidade do seu dashboard quando você já no quer ve-lo lá.
Please login or create an account to save this for later
eSure Power Extend Converter, C48/58-1000
The eSure™ C48/58-1000 Power Extend Converter is a compact device that economically boosts voltage up to -58 VDC to support increasing power needs of remote radio heads on cell towers. The eSure C48/58-1000 plugs into an existing DC distribution panel in the same position as a single-pole bullet circuit breaker, conserving usable space.
Especificações
Technical Specifications
eSure Power Extend Converter, C48/58-1000
- Product Overview
- Power Capacity
- 1000 W
- Current Capacity
- 17.2 A
- System Type
- Converter
- Input
- Input Voltage, Nominal
- -48 VDC
- Output
- Output Voltage, Nominal
- -58 VDC
- Physical Characteristics
- Peso (lbs / kgs)
- 0.45 kg
- Altura (pol/mm)
- 107.2 mm.
- Largura (pol/mm)
- 18.5 mm.
- Profundidade (pol/mm)
- 109.7 mm.
- Environmetal & Standard Compliance
- Temperatura de Operação
- -40°C to +65°C / -40°F to +149°F
- Safety Compliance
- GR3108 Class 2, NEBS Level III, UL (pending)
- EMC Compliance
- FCC CFR 47 Part 15 (Class B conducted and radiated); Telcordia GR-1089-CORE Issue 6
- IM565391 Mounting Kit for NetSure 7000/700 Indoor Systems
- UM565050 C48/58-1000 eSure Power Extend Converter User Manual
- IM565460 Mounting Kit for NetSure 512 Outdoor Enclosure
- IM565649 Mounting Kit for NetSure 502 Systems
- IM60019000 Mounting Kit for NetSure 7100 Compact Systems
- eSure Power Extend Converter Calculator (Dec 2020)
- IM60017372 Mounting Kit for Vertiv 20-Position Breaker Panel
- IM565939 Mounting Kit for NetSure 5100 Systems (582137100)
*Para ver downloads específicos de modelos, é necessário acessar a página de produto específica do modelo, selecionando o nome do modelo na tabela de especificações acima.
